3600 Butterfly

The Orgatech Butterfly 3600 is a high-performance fixture that produces powerful indirect lighting suitable for both indoor and outdoor applications

1/1

Butterfly are powerful indirect LED wall or pendant mounting fixtures providing forward throw indirect lighting.

Slim, clean architectural design with superior performance and eliminating the discomfort of the glare associated with direct LED lighting.

Designed for illuminating large volume spaces such as Malls, Churches, Sports Halls and Airports.

Title	Butterfly 3600
Certifications	UL Listed
CRI	80+
Warranty	5 yr/50,000 hour limited warranty
Environment	IP66 - Suitable for Wet Locations. Natatorium - Marine Grade Finish Operating Temperature - 40˚F to 122˚F
Max Run	N/A
LED Wattage	25W, 50W, 75W, 100W, 150W, 160W, 190W, 240W, 320W
Electrical	120-277V AC or 277-480V AC
Finish	Epoxy Powder Coated Silver, White, Black, Bronze, Custom
Mounting	Flush Mount, Yoke Mount, 4" Swivel Mount, Extended Arm, Pendant Mount (Single, Double)
Optics	Forward throw. Wide forward throw, Rotatable Lenses (every 90 ̊)
Dimming	Non-dimming, 0-10V 10% dimming
CCT	3000K, 3500K, 4000K, 5000K
Length (nom.)	Lengths (nom) 16", 24"
Construction	Durable Die-Cast Aluminum Housing. Stainless Steel Hardware. High impact protective lens
