3600 Butterfly
The Orgatech Butterfly 3600 is a high-performance fixture that produces powerful indirect lighting suitable for both indoor and outdoor applications
1/1
Description
Butterfly are powerful indirect LED wall or pendant mounting fixtures providing forward throw indirect lighting.
Slim, clean architectural design with superior performance and eliminating the discomfort of the glare associated with direct LED lighting.
Designed for illuminating large volume spaces such as Malls, Churches, Sports Halls and Airports.
Resources
Quick Specs
Features | Butterfly 3600 |
---|---|
Certifications | UL Listed |
CRI | 80+ |
Warranty | 5 yr/50,000 hour limited warranty |
Environment | IP66 - Suitable for Wet Locations. Natatorium - Marine Grade Finish Operating Temperature - 40˚F to 122˚F |
Max Run | N/A |
LED Wattage | 25W, 50W, 75W, 100W, 150W, 160W, 190W, 240W, 320W |
Electrical | 120-277V AC or 277-480V AC |
Finish | Epoxy Powder Coated Silver, White, Black, Bronze, Custom |
Mounting | Flush Mount, Yoke Mount, 4" Swivel Mount, Extended Arm, Pendant Mount (Single, Double) |
Optics | Forward throw. Wide forward throw, Rotatable Lenses (every 90 ̊) |
Dimming | Non-dimming, 0-10V 10% dimming |
CCT | 3000K, 3500K, 4000K, 5000K |
Length (nom.) | Lengths (nom) 16", 24" |
Construction | Durable Die-Cast Aluminum Housing. Stainless Steel Hardware. High impact protective lens |
